- DISCONTINUED -
|
Dimensional Math and Conversions
- Work in and convert between building dimensional formats: Yards, Feet-Inch-Fractions, Decimal Feet-Inches and Metric – including Area and Volume
- D:M:S to Decimal Degree conversions
- Find Weight per Volume
Additional Features
- User Preferences: Set custom defined options such as Fractional settings for 1/2” to 1/64” and Stair Headroom Height, Decimal Degrees and more
- Exponential Notation: Enter and display exponential values
- Backspace Key: Makes it easy to change just-entered values
- Constant Operator: Simplifies repetitive calculations
- Cost per Unit: Easily solve unit costing and pricing
- Accumulating Memory (M+) – Plus three additional Memory Storage locations
- Paperless Tape: Review of last 20 entries; double-check totals
- Standard Calculations: works as a regular math calculator with +, -, +/-, x, ÷, %, Π, 1/x, X2, and √
- Automatic Shut-Off saves battery life
|
Built-in Time Saving Functions
- Complete Stair calculations for Risers, Treads, Stringer Length and Incline Angle
- Set Riser Height and solve for Stairwell Opening
- Built-in Right-Angle Functions for Square-ups, Slopes and more
- Area, Volume and Perimeter solutions with Length, Width and Height Keys
- Drywall, Siding and Paneling Key calculates 4x8, 4x9 or 4x12 Sheets to cover an Area
- Roof Function finds Area, Bundles, Squares and 4x8 Sheathing for Flat or Pitched Roofs
- Custom Rafter Function provides Common Rafters, Regular and Irregular Hips, Valleys and Jacks; instant Cutting Angles (Cheek, Level and Plumb)
- Jack Rafter results for Regular and Irregular Pitch Roof. Find Rake-Wall Studs with On-center spacing
- Compound Miter – Store Crown Angle and Enter Wall Corner Angle to calculate the Blade Tilt and Angle for Miters cuts
- Advanced solutions for Circles, Arches, Columns, Cones, Pillars, Windows and Post-holes
- Arched Rake-Walls with On-center Spacing
- Studs – Calculate the number of On-center Studs for an entered Length
- Equal Sided Polygon – Calculate Corner and Bi-sect Angles, Side Length, Perimeter and Area
- Block and Footing solutions
- Board Feet Lumber estimating
|
| |
Includes
- Protective Hard Slide Cover
- Easy-to-follow User's Guide
- Handy Pocket Reference Guide in English and Spanish
- Long-Life Batteries
- Full One-Year Limited Warranty
- English and Spanish CD-ROM with “How To” Video and User’s Guide
|
Tech Specs
- Size:
5.6” x 3.0” x 0.6” (142.8mm x 76.2mm x 15.9mm)
- Product Weight:
4.5 oz. (127.5 gm)
Includes Case and Pocket Reference Guide
- Power:
Two 1.5-volt (LR-44/A76) Long-life Batteries
- Display Type:
11 Digits (7 normal, 4 Fractions) with Full Annunciators
- Display Dimensions:
0.625” x 2.5” (15.88 mm x 63.5 mm)
- Accuracy:
10 Digit Internal Accuracy
|
